Anschutz Radar NX



Maritime collision avoidance with high performance



The Anschütz Radar NX application features a human-centred design, requiring little to no training of crew members. Radar NX features an advanced tracker and clutter suppression that both offer high-performance collision avoidance assistance under any weather and traffic conditions.

ANSCHUTZ RADAR NX

MAIN FEATURES:

  • Advanced target tracking, target association and target management





  • Unique automatic clutter suppression for a clear target display under any conditions (CFAR technology, “Cloud” atmospheric clutter reduction)



  • Individual PPI organisation and filtering on each console due to RAW video transmission from the transceiver to the workstation





  • Chart radar, sortable and filterable target lists, user profiles and many more features (e.g. moving draw objects, blind pilotage and prediction in conjunction with ECDIS NX)





  • Parallel Index Line (PIL) functionality with up to 99 PILs





  • Fully MED type-approved according to IEC 62388





Advanced features



  • Radar Video Merging (RVM) (and distribution to ECDIS). A “virtual transceiver” controls and merges the video of multiple radar sensors. The user is shown a single, seamless 360° image and, thus, an unobstructed radar that significantly improves collision avoidance.



  • ASTERIX server software converts and distributes raw radar videos to the ASTERIX CAT-240 radar video standard, allowing for the distribution of high-definition radar videos to end-user applications, such as oil spill detection radars, ice radars, wave radars or intrusion detection systems.



  • Special applications and naval features such as alarm zones, helicopter guidance, formation manager or camera integration are available for Radar NX.
